SPARK 425 DUO

Digital Diathermy with Dual Outputs Spark 425 Duo is a multi-functional digital surgical diathermy suitable for both open and endoscopic procedures ranging from paediatric to cardiac surgeries. It has the capability to give two monopolar outputs through hand switch pencils. Specialized functions include soft/spray coag, bipolar cutting, combi mode for laparoscopic surgeries etc. Standard features include inbuilt voltage stabilizer, double handswitched output etc.

SPARK 425 DUO

Digital Diathermy with Dual Outputs Spark 425 Duo is a multi-functional digital surgical diathermy suitable for both open and endoscopic procedures ranging from paediatric to cardiac surgeries. It has the capability to give two monopolar outputs through hand switch pencils. Specialized functions include soft/spray coag, bipolar cutting, combi mode for laparoscopic surgeries etc. Standard features include inbuilt voltage stabilizer, double handswitched output etc.

Description

General Description

Digital Diathermy with Dual Outputs Spark 425 Duo is a multi-functional digital surgical diathermy suitable for both open and endoscopic procedures ranging from paediatric to cardiac surgeries. It has the capability to give two monopolar outputs through hand switch pencils. Specialized functions include soft/spray coag, bipolar cutting, combi mode for laparoscopic surgeries etc. Standard features include inbuilt voltage stabilizer, double handswitched output etc.

Technical Specifications

HF Power Display : 3 digit LED display.
HF Power control : Digital control in small increments.

Monopolar Cut

Cut : 400 watts (variable)
Blend : By dedicated switching
TUR : By dedicated switching
Rated frequency : 500 KHz

Monopolar Coagulation

Forced Coag : 100 watts (variable)
Spray Coag : 100 watts (variable)
Soft Coag : 100 watts (variable)
Rated frequency : 500 KHz

Bipolar Coagulation

Standard Coag : 100 watts (variable)
Rated frequency : 500 KHz

Bipolar Cut

Cut : 100 watts (variable)
Rated frequency : 500 KHz

TURP/underwater cutting:

Monopolar outputs same as given above. HF output optimized for TURP

Handswitched output 1 & 2:

Monopolar outputs same as given above

Laparoscopy output:

Monopolar & bipolar outputs same as given above.

Line voltage fluctuation compatibility

Working range : Steady HF output for line voltages from 170 to 250 volts, 50 Hz
Maximum range : Steady HF output for line voltages from 200 to 250 volts, 50 Hz

Internal Power Supply:

High Efficiency Transformer

Physical Dimensions

Size : 400mm x 370mm x 140mm
Weight : 10.5 Kgs
Power consumption : 1000 Watts (230V, 50Hz)

SALIENT FEATURES OF SPARK 425 DUO

Two Monopolar Outputs via handswitch Pencil.
Dedicated TUR Mode for Urology use.
Dedicated Endo Mode for gastro use.
Three types of monopolar coagulation
Soft coag for char free contact coagulation.
Forced coag for sealing bleeders.
Spray coag for wide area superficial non-contact coagulation.
HF output power can be set digitally in small increments
Steady HF output at set value even under line voltage fluctuating conditions
Audio & visual monitoring of patient plate circuit
Combined or independent use of mono & bipolar functions enabled
Autoclavable accessories
Smooth bipolar cut for adhesiolysis
Relatively charring free whitish bipolar coagulation effects
Combination use of mono cut & bipolar coag for laparoscopic surgeries enabled
Separate switching to TUR mode by front panel control

STANDARD ACCESSORIES

Colour coded double pedal footswitch with cable and connector.
Reusable Handswitch surgical pencil with one flat electrode
Reusable Active electrodes handle with set of 4 electrodes & silicone rubber insulated cable
Reusable Insulated bipolar forceps with silicone rubber insulated cable
Silicone rubber patient plate with detachable connection cable and rubber strap with punched holes.

* Due to continuous improvement in design for compliance with International standards, the technical specifications are subject to alterations without notice.
