Description

General Description

This is the standard model available from the Arc series surgical diathermy units. This model is very popular with urologists since it hs a cutting loop life enhancing Rapid Cut function. Also laparoscopic surgeons appreciate its superior quality of bipolar coagulation (full 100 watts whitish coagulation). Also combination use of mono cut with bipolar coagulation is enabled.

Salient Features
  • Highly portable, light weight, compact unit.
  • Line voltage independent performance (PWM technique for power supply).
  • HF output power variable digitally, up to 400 watts..
  • Audio & Visual monitoring of patient plate circuit.
  • Combined or independent use of mono & bipolar functions enabled.
  • Separate generator for monopolar and bipolar functions (100 watts).
  • Autoclavable accessories..
  • More powerful and relatively charring tree bipolar coagulation (100 watts).
  • Smooth bipolar cut for adhesionolysis (100 watts).
  • Combination use of mono cut & bipolar coag for laparoscopic surgeries enabled.
  • SMPS Power supply.
  • Highly portable light weight model.
Standard Accessories
  • Colour coded double pedal footswitch with cable and connector.
  • Silicone rubber patient plate with detachable connection cable& rubber strap with holes.
  • Reusable Active electrode handle with set of 4 electrodes & silicone rubber insulated cable.
  • Reusable insulated bipolar forceps with silicone rubber insulated cable.
  • Reusable Handswitch surgical pencil with one blade electrode
Technical Specifications
  • Monopolar Cutting : 400 Watts.
  • Monopolar Coag : 100 watts.
  • Monopolar Spray Coag : 100 watts.
  • Blend in 2 steps.
  • Bipolar Coagulation Power : 100 Watts.
  • Monopolar Rated frequency: 500 KHz.
  • Bipolar Rated frequency: 1000 KHz.
  • Power supply : 230 Volts, 50 Hz.
  • Line Voltage Fluctuation Compatibility.
Physical Dimensions
  • Unit size : 370 x 325 x 120 mm
  • Unit gross weight : 7 Kgs

* Due to continuous improvement in design for compliance with International standards, the technical specifications are subject to alterations without notice.
